swanser.f90 File Reference

Go to the source code of this file.

Functions/Subroutines
subroutine	readxy (NAMX, NAMY, XX, YY, KONT, XSTA, YSTA)
subroutine	txpbla (TEXT, IF, IL)
character *20 function	numstr (IVAL, RVAL, FORM)
subroutine	swcopi (IARR1, IARR2, LENGTH)
subroutine	kscip1 (MMT, SIG, D, K, CG, N, ND)
subroutine	kscip2 (S, D, CG)
character *20 function	intstr (IVAL)
real function	gamma (XX)
function	gammln (XX)
subroutine	sshape (ACLOC, SPCSIG, SPCDIR, FSHAPL, DSHAPL)
real function	degcnv (DEGREE)
subroutine	swanout (DEP2)

Function/Subroutine Documentation

degcnv()

real function degcnv

(

real

DEGREE

)

Definition at line 1225 of file swanser.f90.

!                                                                      *
!***********************************************************************
!
      USE swcomm3

      IMPLICIT NONE
!
!
!   --|-----------------------------------------------------------|--
!     | Delft University of Technology                            |
!     | Faculty of Civil Engineering                              |
!     | Environmental Fluid Mechanics Section                     |
!     | P.O. Box 5048, 2600 GA  Delft, The Netherlands            |
!     |                                                           |
!     | Programmers: R.C. Ris, N. Booij,                          |
!     |              IJ.G. Haagsma, A.T.M.M. Kieftenburg,         |
!     |              M. Zijlema, E.E. Kriezi,                     |
!     |              R. Padilla-Hernandez, L.H. Holthuijsen       |
!   --|-----------------------------------------------------------|--
!
!
!     SWAN (Simulating WAves Nearshore); a third generation wave model
!     Copyright (C) 2004-2005  Delft University of Technology
!
!     This program is free software; you can redistribute it and/or
!     modify it under the terms of the GNU General Public License as
!     published by the Free Software Foundation; either version 2 of
!     the License, or (at your option) any later version.
!
!     This program is distributed in the hope that it will be useful,
!     but WITHOUT ANY WARRANTY; without even the implied warranty of
!     MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the
!     GNU General Public License for more details.
!
!     A copy of the GNU General Public License is available at
!     http://www.gnu.org/copyleft/gpl.html#SEC3
!     or by writing to the Free Software Foundation, Inc.,
!     59 Temple Place, Suite 330, Boston, MA  02111-1307  USA
!
!
!  0. Authors
!
!  1. UPDATE
!
!       SEP 1997: New for SWAN 32.01
!                 Cor van der Schelde - Delft Hydraulics
!       30.70, Feb. 98: test output suppressed (causes problem if subr
!                       is used during output
!
!  2. PURPOSE
!
!       Transform degrees from nautical to cartesian or vice versa.
!
!  3. METHOD
!
!       DEGCNV = 180 + dnorth - degree
!
!  4. PARAMETERLIST
!
!       DEGCNV      direction in cartesian or nautical degrees.
!       DEGREE      direction in nautical or cartesian degrees.
!
!  5. SUBROUTINES CALLING
!
!       ---
!
!  6. SUBROUTINES USED
!
!       NONE
!
!  7. ERROR MESSAGES
!
!       NONE
!
!  8. REMARKS
!
!           Nautical convention           Cartesian convention
!
!                    0                             90
!                    |                              |
!                    |                              |
!                    |                              |
!                    |                              |
!        270 --------+-------- 90       180 --------+-------- 0
!                    |                              |
!                    |                              |
!                    |                              |
!                    |                              |
!                   180                            270
!
!  9. STRUCTURE
!
!     ---------------------------------
!     IF (NAUTICAL DEGREES) THEN
!       CONVERT DEGREES
!     IF (DEGREES > 360 OR < 0) THEN
!       CORRECT DEGREES WITHIN 0 - 360
!     ---------------------------------
!
! 10. SOURCE TEXT
!
!***********************************************************************
!
      INTEGER :: IENT
      REAL    :: DEGREE

      SAVE ient
      DATA ient /0/
      CALL strace(ient,'DEGCNV')
!
      IF ( bnaut ) THEN
        degcnv = 180. + dnorth - degree
      ELSE
        degcnv = degree
      ENDIF
!
      IF (degcnv >= 360.) THEN
        degcnv = mod(degcnv, 360.)
      ELSE IF (degcnv < 0.) THEN
        degcnv = mod(degcnv, 360.) + 360.
      ELSE
!       DEGCNV between 0 and 360; do nothing
      ENDIF
!
      RETURN

Here is the call graph for this function:

Here is the caller graph for this function:

gamma()

real function gamma

(

real

XX

)

Definition at line 788 of file swanser.f90.

!                                                                   *
!********************************************************************
!
!   Updates
!     ver 30.70, Oct 1997 by N.Booij: new subroutine
!
!   Purpose
!     Compute the transcendental function Gamma
!
!   Subroutines used
!     GAMMLN  (Numerical Recipes)
!
      REAL XX, YY, ABIG
      SAVE ient, abig
      DATA ient /0/, abig /30./
      CALL strace (ient, 'GAMMA')
      yy = gammln(xx)
      IF (yy.GT.abig) yy = abig
      IF (yy.LT.-abig) yy = -abig
      gamma = exp(yy)
      RETURN

Here is the call graph for this function:

Here is the caller graph for this function:

gammln()

function gammln

(

XX

)

Definition at line 814 of file swanser.f90.

!                                                                   *
!********************************************************************
!
!   Method:
!     function is copied from: Press et al., "Numerical Recipes"
!
      DOUBLE PRECISION  COF(6),STP,HALF,ONE,FPF,X,TMP,SER
      DATA cof,stp/76.18009173d0,-86.50532033d0,24.01409822d0,     &
          -1.231739516d0,.120858003d-2,-.536382d-5,2.50662827465d0/
      DATA half,one,fpf/0.5d0,1.0d0,5.5d0/
      x=xx-one
      tmp=x+fpf
      tmp=(x+half)*log(tmp)-tmp
      ser=one
      DO 11 j=1,6
        x=x+one
        ser=ser+cof(j)/x
11    CONTINUE
      gammln=tmp+log(stp*ser)
      RETURN

Here is the caller graph for this function:

intstr()

character*20 function intstr

(

integer

IVAL

)

Definition at line 696 of file swanser.f90.

!
!****************************************************************
!
      IMPLICIT NONE
!
!
!   --|-----------------------------------------------------------|--
!     | Delft University of Technology                            |
!     | Faculty of Civil Engineering and Geosciences              |
!     | Environmental Fluid Mechanics Section                     |
!     | P.O. Box 5048, 2600 GA  Delft, The Netherlands            |
!     |                                                           |
!     | Programmer: M. Zijlema                                    |
!   --|-----------------------------------------------------------|--
!
!
!     SWAN (Simulating WAves Nearshore); a third generation wave model
!     Copyright (C) 2004-2005  Delft University of Technology
!
!     This program is free software; you can redistribute it and/or
!     modify it under the terms of the GNU General Public License as
!     published by the Free Software Foundation; either version 2 of
!     the License, or (at your option) any later version.
!
!     This program is distributed in the hope that it will be useful,
!     but WITHOUT ANY WARRANTY; without even the implied warranty of
!     MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the
!     GNU General Public License for more details.
!
!     A copy of the GNU General Public License is available at
!     http://www.gnu.org/copyleft/gpl.html#SEC3
!     or by writing to the Free Software Foundation, Inc.,
!     59 Temple Place, Suite 330, Boston, MA  02111-1307  USA
!
!
!  0. Authors
!
!     40.23: Marcel Zijlema
!
!  1. Updates
!
!     40.23, Feb. 03: New subroutine
!
!  2. Purpose
!
!     Convert integer to string
!
!  4. Argument variables
!
!     IVAL        integer to be converted
!
      INTEGER IVAL
!
!  6. Local variables
!
!     CVAL  :     character represented an integer of mantisse
!     I     :     counter
!     IPOS  :     position in mantisse
!     IQUO  :     whole quotient
!
      INTEGER I, IPOS, IQUO
      CHARACTER*1, ALLOCATABLE :: CVAL(:)
!
! 12. Structure
!
!     Trivial.
!
! 13. Source text
!
      ipos = 1
 100  CONTINUE
      IF (ival/10**ipos.GE.1.) THEN
         ipos = ipos + 1
         GO TO 100
      END IF
      ALLOCATE(cval(ipos))

      DO i=ipos,1,-1
         iquo=ival/10**(i-1)
         cval(ipos-i+1)=char(int(iquo)+48)
         ival=ival-iquo*10**(i-1)
      END DO

      WRITE (intstr,*) (cval(i), i=1,ipos)

      RETURN

kscip1()

subroutine kscip1	(	integer	MMT,
		real, dimension(mmt)	SIG,
		real	D,
		real, dimension(mmt)	K,
		real, dimension(mmt)	CG,
		real, dimension(mmt)	N,
		real, dimension(mmt)	ND
	)

Definition at line 504 of file swanser.f90.

!                                                                      *
!***********************************************************************
!
    USE ocpcomm4
    USE swcomm3
!
    IMPLICIT NONE
!
!   --|-----------------------------------------------------------|--
!     | Delft University of Technology                            |
!     | Faculty of Civil Engineering                              |
!     | Environmental Fluid Mechanics Section                     |
!     | P.O. Box 5048, 2600 GA  Delft, The Netherlands            |
!     |                                                           |
!     | Programmers: R.C. Ris, N. Booij,                          |
!     |              IJ.G. Haagsma, A.T.M.M. Kieftenburg,         |
!     |              M. Zijlema, E.E. Kriezi,                     |
!     |              R. Padilla-Hernandez, L.H. Holthuijsen       |
!   --|-----------------------------------------------------------|--
!
!  0. Authors
!
!  1. Updates
!
!  2. Purpose
!
!     Calculation of the wave number, group velocity, group number N
!     and the derivative of N w.r.t. depth (=ND)
!
!  3. Method
!
!     --
!
!  4. Argument variables
!
!     MMT     input    number of frequency points
!
      INTEGER   MMT
!
!     CG      output   group velocity
!     D       input    local depth
!     K       output   wave number
!     N       output   ratio of group and phase velocity
!     ND      output   derivative of N with respect to D
!     SIG     input    rel. frequency for which wave parameters
!                      must be determined
!
      REAL      CG(MMT), D,                                    &
                K(MMT), N(MMT), ND(MMT), SIG(MMT)
!
!  6. Local variables
!
!     C         phase velocity
!     FAC1      auxiliary factor
!     FAC2      auxiliary factor
!     FAC3      auxiliary factor
!     IENT      number of entries
!     IS        counter in frequency (sigma-space)
!     KND       dimensionless wave number
!     ROOTDG    square root of D/GRAV
!     WGD       square root of GRAV*D
!     SND       dimensionless frequency
!     SND2      = SND*SND
!
      INTEGER   IENT, IS
      REAL      KND, ROOTDG, SND, WGD, SND2, C, FAC1, FAC2, FAC3
!
!  8. Subroutines used
!
!     --
!
!  9. Subroutines calling
!
!     SWOEXA, SWOEXF (Swan/Output)
!
! 10. Error messages
!
!     --
!
! 11. Remarks
!
!     --
!
! 12. Structure
!
!     -----------------------------------------------------------------
!      Compute non-dimensional frequency SND
!      IF SND >= 2.5, then
!        Compute wave number K, group velocity CGO, ratio of group
!        and phase velocity N and its derivative ND according to
!        deep water theory
!      ELSE IF SND =< 1.e-6
!        Compute wave number K, group velocity CGO, ratio of group
!        and phase velocity N and its derivative ND
!        according to extremely shallow water
!      ELSE
!        Compute wave number K, group velocity CGO and the ratio of
!        group and phase velocity N by Pade and other simple formulas.
!        Compute the derivative of N w.r.t. D = ND.
!     -----------------------------------------------------------------
!
! 13. Source text
!
!    SAVE IENT
!    DATA IENT /0/
!    IF (LTRACE) CALL STRACE (IENT, 'KSCIP1')
!
    rootdg = sqrt(d/grav_w)
    wgd    = rootdg*grav_w
    DO is = 1, mmt
!     SND is dimensionless frequency
      snd = sig(is) * rootdg
      IF(snd >= 2.5)THEN
!     ******* deep water *******
        k(is)  = sig(is) * sig(is) / grav_w
        cg(is) = 0.5 * grav_w / sig(is)
        n(is)  = 0.5
        nd(is) = 0.
      ELSE IF(snd < 1.e-6)THEN
!     *** very shallow water ***
!        print*,'IN VERY SHALLOW WATER'
!   stop
        k(is)  = snd/d
        cg(is) = wgd
        n(is)  = 1.
        nd(is) = 0.
      ELSE
        snd2  = snd*snd
        c     = sqrt(grav_w*d/(snd2+1./(1.+0.666*snd2+0.445*snd2**2      &
            -0.105*snd2**3+0.272*snd2**4)))
        k(is) = sig(is)/c
        knd   = k(is)*d
        fac1  = 2.*knd/sinh(2.*knd)
        n(is) = 0.5*(1.+fac1)
        cg(is)= n(is)*c
        fac2  = snd2/knd
        fac3  = 2.*fac2/(1.+fac2*fac2)
        nd(is)= fac1*(0.5/d - k(is)/fac3)
      ENDIF
    END DO

    RETURN

Here is the caller graph for this function:

kscip2()

subroutine kscip2	(	real, dimension(msc)	S,
		real	D,
		real, dimension(msc)	CG
	)

Definition at line 650 of file swanser.f90.

!                                                                      *
!***********************************************************************
!
    USE ocpcomm4
    USE swcomm3
!
    IMPLICIT NONE
      REAL      CG(MSC), D, K,S(MSC)
      INTEGER   IENT, IS
      REAL      KND, ROOTDG, SND, WGD, SND2, C, FAC1,N
    rootdg = sqrt(d/grav_w)
    wgd    = rootdg*grav_w
!     SND is dimensionless frequency
     DO is=1,msc
      snd = s(is) * rootdg
      IF(snd >= 2.5)THEN
!     ******* deep water *******
        k = s(is) * s(is) / grav_w
        cg(is) = 0.5 * grav_w / s(is)
      ELSE IF(snd < 1.e-6)THEN
!     *** very shallow water ***
!        print*,'IN VERY SHALLOW WATER'
!       stop
        k  = snd/d
        cg(is) = wgd
      ELSE
        snd2  = snd*snd
        c     = sqrt(grav_w*d/(snd2+1./(1.+0.666*snd2+0.445*snd2**2      &
                -0.105*snd2**3+0.272*snd2**4)))
        k = s(is)/c
        knd   = k*d
        fac1  = 2.*knd/sinh(2.*knd)
        n = 0.5*(1.+fac1)
        cg(is)= n*c
      ENDIF
    END DO
    RETURN

Here is the caller graph for this function:

numstr()

character*20 function numstr	(	integer	IVAL,
		real	RVAL,
		character	FORM
	)

Definition at line 305 of file swanser.f90.

!
!****************************************************************
!
    USE ocpcomm4
!
    IMPLICIT NONE
!
!
!   --|-----------------------------------------------------------|--
!     | Delft University of Technology                            |
!     | Faculty of Civil Engineering and Geosciences              |
!     | Environmental Fluid Mechanics Section                     |
!     | P.O. Box 5048, 2600 GA  Delft, The Netherlands            |
!     |                                                           |
!     | Programmer: M. Zijlema                                    |
!   --|-----------------------------------------------------------|--
!
!
!     SWAN (Simulating WAves Nearshore); a third generation wave model
!     Copyright (C) 2004-2005  Delft University of Technology
!
!     This program is free software; you can redistribute it and/or
!     modify it under the terms of the GNU General Public License as
!     published by the Free Software Foundation; either version 2 of
!     the License, or (at your option) any later version.
!
!     This program is distributed in the hope that it will be useful,
!     but WITHOUT ANY WARRANTY; without even the implied warranty of
!     MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the
!     GNU General Public License for more details.
!
!     A copy of the GNU General Public License is available at
!     http://www.gnu.org/copyleft/gpl.html#SEC3
!     or by writing to the Free Software Foundation, Inc.,
!     59 Temple Place, Suite 330, Boston, MA  02111-1307  USA
!
!
!  0. Authors
!
!     40.23: Marcel Zijlema
!     40.41: Marcel Zijlema
!
!  1. Updates
!
!     40.23, Feb. 03: New subroutine
!     40.41, Oct. 04: common blocks replaced by modules, include files removed
!
!  2. Purpose
!
!     Convert integer or real to string with given format
!
!  4. Argument variables
!
!     IVAL        integer to be converted
!     FORM        given format
!     RVAL        real to be converted
!
    INTEGER   IVAL
    REAL      RVAL
    CHARACTER FORM*20
!
!  6. Local variables
!
! 12. Structure
!
!     Trivial.
!
! 13. Source text
!
    IF(ival /= inan)THEN
      WRITE(numstr,form) ival
    ELSE IF( rval /= rnan)THEN
      WRITE (numstr,form) rval
    ELSE
      numstr = ''
    END IF

    RETURN

Here is the caller graph for this function:

readxy()

subroutine readxy	(	character, dimension(*)	NAMX,
		character, dimension(*)	NAMY,
			XX,
			YY,
		character, dimension(*)	KONT,
			XSTA,
			YSTA
	)

Definition at line 63 of file swanser.f90.

!                                                                      *
!***********************************************************************
!
   USE ocpcomm1
   USE swcomm2
!
!
!   --|-----------------------------------------------------------|--
!     | Delft University of Technology                            |
!     | Faculty of Civil Engineering                              |
!     | Environmental Fluid Mechanics Section                     |
!     | P.O. Box 5048, 2600 GA  Delft, The Netherlands            |
!     |                                                           |
!     | Programmers: R.C. Ris, N. Booij,                          |
!     |              IJ.G. Haagsma, A.T.M.M. Kieftenburg,         |
!     |              M. Zijlema, E.E. Kriezi,                     |
!     |              R. Padilla-Hernandez, L.H. Holthuijsen       |
!   --|-----------------------------------------------------------|--
!
!
!     SWAN (Simulating WAves Nearshore); a third generation wave model
!     Copyright (C) 2004-2005  Delft University of Technology
!
!     This program is free software; you can redistribute it and/or
!     modify it under the terms of the GNU General Public License as
!     published by the Free Software Foundation; either version 2 of
!     the License, or (at your option) any later version.
!
!     This program is distributed in the hope that it will be useful,
!     but WITHOUT ANY WARRANTY; without even the implied warranty of
!     MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the
!     GNU General Public License for more details.
!
!     A copy of the GNU General Public License is available at
!     http://www.gnu.org/copyleft/gpl.html#SEC3
!     or by writing to the Free Software Foundation, Inc.,
!     59 Temple Place, Suite 330, Boston, MA  02111-1307  USA
!
!
!  0. Authors
!     40.22: John Cazes and Tim Campbell
!     40.13: Nico Booij
!     40.51: Marcel Zijlema
!
!  1. UPDATE
!
!       Nov. 1996               offset values are added to standard values
!                               because they will be subtracted later
!     40.13, Nov. 01: a valid value for YY is required if a valid value
!                     for XX has been given; ocpcomm1.inc reactivated
!     40.51, Feb. 05: correction to location points equal to offset values
!
!  2. PURPOSE
!
!       Read x and y, initialize offset values XOFFS and YOFFS
!
!  3. METHOD
!
!       ---
!
!  4. PARAMETERLIST
!
!       NAMX, NAMY   inp char    names of the two coordinates as given in
!                                the user manual
!       XX, YY       out real    values of x and y taking into account offset
!       KONT         inp char    what to be done if values are missing
!                                see doc. of INDBLE (Ocean Pack doc.)
!       XSTA, YSTA   inp real    standard values of x and y
!
!  5. SUBROUTINES CALLING
!
!
!
!  6. SUBROUTINES USED
!
!       INDBLE (Ocean Pack)
   LOGICAL EQREAL
!
!  7. ERROR MESSAGES
!
!       ---
!
!  8. REMARKS
!
!       ---
!
!  9. STRUCTURE
!
!       ----------------------------------------------------------------
!       Read x and y in double prec.
!       If this is first couple of values
!       Then assign values to XOFFS and YOFFS
!            make LXOFFS True
!       ---------------------------------------------------------------
!       make XX and YY equal to x and y taking into account offset
!       ----------------------------------------------------------------
!
! 10. SOURCE TEXT
!
   DOUBLE PRECISION XTMP, YTMP
   CHARACTER  NAMX *(*), NAMY *(*), KONT *(*)
   SAVE  ient
   DATA  ient /0/
   CALL  strace (ient,'READXY')
!
!JQI   CALL INDBLE (NAMX, XTMP, KONT, DBLE(XSTA)+DBLE(XOFFS))
   IF(chgval)THEN
!       a valid value was given for XX
!JQI     CALL INDBLE (NAMY, YTMP, 'REQ', DBLE(YSTA)+DBLE(YOFFS))
   ELSE
!JQI     CALL INDBLE (NAMY, YTMP, KONT, DBLE(YSTA)+DBLE(YOFFS))
   ENDIF
   IF(.NOT.lxoffs)THEN
     xoffs = real(xtmp)
     yoffs = real(ytmp)
     lxoffs = .true.
   ENDIF
!JQI   IF(.NOT.EQREAL(XOFFS,REAL(XTMP)))THEN
!JQI     XX = REAL(XTMP-DBLE(XOFFS))
!JQI   ELSE IF(OPTG == 3)THEN
!JQI     XX = 1.E-5
!JQI   ELSE
!JQI     XX = 0.
!JQI   END IF
!JQI   IF(.NOT.EQREAL(YOFFS,REAL(YTMP)))THEN
!JQI     YY = REAL(YTMP-DBLE(YOFFS))
!JQI   ELSE IF(OPTG == 3)THEN
!JQI     YY = 1.E-5
!JQI   ELSE
!JQI     YY = 0.
!JQI   END IF
!
   RETURN

Here is the call graph for this function:

sshape()

subroutine sshape	(	real, dimension(mdc,msc)	ACLOC,
		real, dimension(msc)	SPCSIG,
		real, dimension(mdc,6)	SPCDIR,
		integer	FSHAPL,
		integer	DSHAPL
	)

Definition at line 840 of file swanser.f90.

!                                                                      *
!***********************************************************************
!
      USE ocpcomm4
      USE swcomm3
!
!  0. Authors
!
!  1. Updates
!
!  2. Purpose
!
!     Calculating of energy density at boundary point (x,y,sigma,theta)
!
!  3. Method (updated...)
!
!     see: M. Yamaguchi: Approximate expressions for integral properties
!          of the JONSWAP spectrum; Proc. JSCE, No. 345/II-1, pp. 149-152,
!          1984.
!
!     computation of mean period: see Swan system documentation
!
!  4. Argument variables
!
!   o ACLOC : Energy density at a point in space
! i   SPCDIR: (*,1); spectral directions (radians)                        30.82
!             (*,2); cosine of spectral directions                        30.82
!             (*,3); sine of spectral directions                          30.82
!             (*,4); cosine^2 of spectral directions                      30.82
!             (*,5); cosine*sine of spectral directions                   30.82
!             (*,6); sine^2 of spectral directions                        30.82
! i   SPCSIG: Relative frequencies in computational domain in sigma-space 30.82
!
      REAL    ACLOC(MDC,MSC)
      REAL    SPCDIR(MDC,6)
      REAL    SPCSIG(MSC)
!
! i   DSHAPL: Directional distribution
! i   FSHAPL: Shape of spectrum:
!             =1; Pierson-Moskowitz spectrum
!             =2; Jonswap spectrum
!             =3; bin
!             =4; Gauss curve
!             (if >0: period is interpreted as peak per.
!              if <0: period is interpreted as mean per.)
!
      INTEGER FSHAPL, DSHAPL
!
!  5. Parameter variables
!
!  6. Local variables
!
!     ID       counter of directions
!     IS       counter of frequencies
!     LSHAPE   absolute value of FSHAPL
!
      INTEGER  ID, IS, LSHAPE
!
!     PKPER    peak period                                                30.80
!     APSHAP   aux. var. used in computation of spectrum
!     AUX1     auxiliary variable
!     AUX2     auxiliary variable
!     AUX3     auxiliary variable
!     COEFF    coefficient for behaviour around the peak (Jonswap)
!     CPSHAP   aux. var. used in computation of spectrum
!     CTOT     total energy
!     CTOTT    total energy (used for comparison)
!     DIFPER   auxiliary variable used to select bin closest
!              to given frequency
!     MPER
!     MS       power in directional distribution
!     RA       action density
!     SALPHA
!     SF       frequency (Hz)
!     SF4      SF**4
!     SF5      SF**5
!     FPK      frequency corresponding to peak period (1/PKPER)           30.80
!     FPK4     FPK**4
!     SYF      peakedness parameter
!
      REAL     APSHAP, AUX1, AUX2, AUX3
      REAL     COEFF ,SYF   ,MPER  ,CTOT  ,CTOTT,PKPER  ,DIFPER
      REAL     MS
      REAL     RA    ,SALPHA,SF   ,SF4   ,SF5   ,FPK   ,FPK4, FAC
!
!     LOGPM    indicates whether peak or mean frequency is used
!     DVERIF   logical used in verification of incident direction
!
      LOGICAL  LOGPM, DVERIF
!
!     PSHAPE   coefficients of spectral distribution (see remarks)
!     SPPARM   array containing integral wave parameters (see remarks)
!
!  8. Subroutines used
!
!     ---
!
!  9. Subroutines calling
!
! 10. Error messages
!
! 11. Remarks
!
!     PSHAPE(1): SY0, peak enhancement factor (gamma) in Jonswap spectrum
!     PSHAPE(2): spectral width in case of Gauss spectrum in rad/s
!
!     SPPARM    real     input    incident wave parameters (Hs, Period,
!                                 direction, Ms (dir. spread))
!     SPPARM(1): Hs, sign. wave height
!     SPPARM(2): Wave period given by the user (either peak or mean)      30.80
!     SPPARM(3): average direction
!     SPPARM(4): directional spread
!
!     ---------------------------------------------------------------------
!
!     In the case of a JONSWAP spectrum the initial conditions are given by
!                   _               _       _       _       _
!                  |       _   _ -4  |     |       | S - S   |
!             2    |      |  S  |    |     |       |      p  |
!          a g     |      |  _  |    |  exp|-1/2 * |________ |* 2/pi COS(T-T  )
! E(S,D )= ___  exp|-5/4 *|  S  |    | G   |       | e * S   |              wi
!      wa    5     |      |   p |    |     |_      |_     p _|
!           S      |      |_   _|    |
!                  |_               _|
!
!   where
!         S   : rel. frequency
!
!         D   : Dir. of wave component
!          wa
!
!         a   : equili. range const. (Phillips' constant)
!         g   : gravity acceleration
!
!         S   : Peak frequency
!          p
!
!         G   : Peak enhancement factor
!         e   : Peak width
!
!         T   : local wind direction
!          wi
!
! 12. Structure
!
!       ----------------------------------------------------------------
!       case shape
!       =1:   calculate value of Pierson-Moskowitz spectrum
!       =2:   calculate value of Jonswap spectrum
!       =3:   calculate value of bin spectrum
!       =4:   calculate value of Gauss spectrum
!       else: Give error message because of wrong shape
!       ----------------------------------------------------------------
!       if LOGPM is True
!       then calculate average period
!            if it differs from given average period
!            then recalculate peak period
!                 restart procedure to compute spectral shape
!       ----------------------------------------------------------------
!       for all spectral bins do
!            multiply all action densities by directional distribution
!       ----------------------------------------------------------------
!
! 13. Source text
!
      SAVE     ient
      DATA     ient/0/
      CALL strace(ient,'SSHAPE')
!
      IF (itest >= 80) WRITE (prtest, 8) fshapl, dshapl,          &
                                         (spparm(jj), jj = 1,4)
   8  FORMAT (' entry SSHAPE ', 2i3, 4e12.4)
      IF(fshapl < 0)THEN
        lshape = - fshapl
        logpm  = .false.
      ELSE
        lshape = fshapl
        logpm  = .true.
      ENDIF

!
      IF(spparm(1) <= 0.)                                         &
         CALL msgerr(1,' sign. wave height at boundary is not positive')
!
      pkper = spparm(2)
      itper = 0
      IF(lshape == 3)THEN
!       select bin closest to given period
        difper = 1.e10
        DO is = 1, msc
          IF(abs(pkper - pi2_w/spcsig(is)) < difper)THEN
            isp = is
            difper = abs(pkper - pi2_w/spcsig(is))
          ENDIF
        ENDDO
      ENDIF
!
!     compute spectral shape using peak period PKPER
!
      fac  = 1.
 100  fpk  = (1./pkper)
      fpk4 = fpk**4
      IF(lshape == 1)THEN
        salpha = ((spparm(1) ** 2) * (fpk4)) * 5. / 16.
      ELSE IF(lshape == 2)THEN
!       *** SALPHA = alpha*(grav**2)/(2.*pi)**4)
        salpha = (spparm(1)**2 * fpk4) /                            &
             ((0.06533*(pshape(1)**0.8015)+0.13467)*16.)
      ELSE IF(lshape == 4)THEN
        aux1 = spparm(1)**2 / ( 16.* sqrt(pi2_w) * pshape(2))
        aux3 = 2. * pshape(2)**2
      ENDIF
!
      ctott = 0.
      DO is = 1, msc
!
        IF(lshape == 1)THEN
!         *** LSHAPE = 1 : Pierson and Moskowitz ***
          sf = spcsig(is) / pi2_w
          sf4 = sf**4
          sf5 = sf**5
          ra = (salpha/sf5)*exp(-(5.*fpk4)/(4.*sf4))/(pi2_w*spcsig(is))
          acloc(mdc,is) = ra
        ELSE IF(lshape == 2)THEN
!         *** LSHAPE = 2 : JONSWAP ***
          sf = spcsig(is)/(pi2_w)
          sf4 = sf**4
          sf5 = sf**5
          cpshap = 1.25 * fpk4 / sf4
          IF(cpshap > 10.)THEN
            ra = 0.
          ELSE
            ra = (salpha/sf5) * exp(-cpshap)
          ENDIF
          IF(sf < fpk)THEN
            coeff = 0.07
          ELSE
            coeff = 0.09
          ENDIF
          apshap =  0.5 * ((sf-fpk) / (coeff*fpk)) **2
          IF(apshap > 10.)THEN
            syf = 1.
          ELSE
            ppshap = exp(-apshap)
            syf = pshape(1)**ppshap
          ENDIF
          ra = syf*ra/(spcsig(is)*pi2_w)
          acloc(mdc,is) = ra
          IF(itest >= 120) WRITE (prtest, 112)                  &
                sf, salpha, cpshap, apshap, syf, ra
 112      FORMAT (' SSHAPE freq. ', 8e12.4)
        ELSE IF(lshape == 3)THEN
!
!         *** all energy concentrated in one BIN ***
!
          IF(is == isp)THEN
            acloc(mdc,is) = ( spparm(1)**2 ) /                   &
                        ( 16. * spcsig(is)**2 * frintf )
          ELSE
            acloc(mdc,is) = 0.
          ENDIF
        ELSE IF(lshape == 4)THEN
!
!         *** energy Gaussian distributed (wave-current tests) ***
!
          aux2 = ( spcsig(is) - ( pi2_w / pkper ) )**2
          ra = aux1 * exp( -1. * aux2 / aux3 ) / spcsig(is)
          acloc(mdc,is) = ra
        ELSE
          IF(is == 1)THEN
            CALL msgerr (2,'Wrong type for frequency shape')
            WRITE (printf, *) ' -> ', fshapl, lshape
          ENDIF
        ENDIF
        IF (itest >= 10)                                         &
            ctott = ctott + frintf * acloc(mdc,is) * spcsig(is)**2
      END DO   !END DO IS
      IF(itest >= 10)THEN
        IF(spparm(1) > 0.01)THEN
          hstmp = 4. * sqrt(ctott)
          IF(abs(hstmp-spparm(1)) > 0.1*spparm(1))           &
          WRITE (printf, 303) spparm(1), hstmp
 303      FORMAT (' SSHAPE, deviation in Hs, should be ', f8.3,      &
                  ', calculated ', f8.3)
        ENDIF
      ENDIF
!
!     if mean frequency was given recalculate PKPER and restart
!
      IF (.NOT.logpm .AND. itper < 10)THEN
        itper = itper + 1
!       calculate average frequency
        am0 = 0.
        am1 = 0.
        DO is = 1, msc
          as2 = acloc(mdc,is) * (spcsig(is))**2
          as3 = as2 * spcsig(is)
          am0 = am0 + as2
          am1 = am1 + as3
        ENDDO
!       contribution of tail to total energy density
        pptail = pwtail(1) - 1.
        aptail = 1. / (pptail * (1. + pptail * (frinth-1.)))
        am0 = am0 * frintf + aptail * as2
        pptail = pwtail(1) - 2.
        eptail = 1. / (pptail * (1. + pptail * (frinth-1.)))
        am1 = am1 * frintf + eptail * as3
!       Mean period:
        IF( am1 /= 0.)THEN
           mper = pi2_w * am0 / am1
        ELSE
           CALL msgerr(3, ' first moment is zero in calculating the')
           CALL msgerr(3, ' spectrum at boundary using param. bc.')
        END IF
        IF(itest >= 80) WRITE (prtest, 72) itper, spparm(2), mper,     &
                                        pkper
  72    FORMAT (' SSHAPE iter=', i2, '  period values:', 3f7.2)
        IF(abs(mper-spparm(2)) > 0.01*spparm(2))THEN
!         modification suggested by Mauro Sclavo
          pkper = (spparm(2) / mper) * pkper
          GOTO 100
        ENDIF
      ENDIF
!
      IF (itper >= 10)THEN
        CALL msgerr(3, 'No convergence calculating the spectrum')
        CALL msgerr(3, 'at the boundary using parametric bound. cond.')
      ENDIF
!
!     now introduce distribution over directions
!
      adir = pi_w * degcnv(spparm(3)) / 180.
      IF(dshapl == 1)THEN
        dspr = pi_w * spparm(4) / 180.
        ms = max(dspr**(-2) - 2., 1.)
      ELSE
        ms = spparm(4)
      ENDIF
      IF(ms < 12.)THEN
        ctot = (2.**ms) * (gamma(0.5*ms+1.))**2 / (pi_w * gamma(ms+1.))
      ELSE
        ctot =  sqrt(0.5*ms/pi_w) / (1. - 0.25/ms)
      ENDIF
      IF(itest >= 100)THEN
        esom = 0.
        DO is = 1, msc
          esom = esom + frintf * spcsig(is)**2 * acloc(mdc,is)
        ENDDO
        WRITE (prtest, *) ' SSHAPE dir ', 4.*sqrt(abs(esom)),         &
           spparm(1), ctot, ms, gamma(0.5*ms+1.), gamma(ms+1.),   &
           ctot
      ENDIF
      dverif = .false.
      ctott = 0.
      DO id = 1, mdc
        acos = cos(spcdir(id,1) - adir)
        IF(acos > 0.)THEN
          cdir = ctot * max(acos**ms, 1.e-10)
          IF(.NOT.fulcir)THEN
            IF(acos >= cos(ddir)) dverif = .true.
          ENDIF
        ELSE
          cdir = 0.
        ENDIF
        IF(itest >= 10) ctott = ctott + cdir * ddir
        IF(itest >= 100) WRITE (prtest, 360) id,spcdir(id,1),cdir
 360    FORMAT (' ID Spcdir Cdir: ',i3,3(1x,e11.4))
        DO is = 1, msc
          acloc(id,is) = cdir * acloc(mdc,is)
        ENDDO
      ENDDO
      IF(itest >= 10)THEN
        IF(abs(ctott-1.) > 0.1) WRITE (printf, 363) ctott
 363    FORMAT (' SSHAPE, integral of Cdir is not 1, but:', f6.3)
      ENDIF
      IF (.NOT.fulcir .AND. .NOT.dverif)                   &
         CALL msgerr (1, 'incident direction is outside sector')
!
      RETURN

Here is the call graph for this function:

swanout()

subroutine swanout

(

DEP2

)

Definition at line 1356 of file swanser.f90.

      RETURN

swcopi()

subroutine swcopi	(	integer, dimension(length)	IARR1,
		integer, dimension(length)	IARR2,
		integer	LENGTH
	)

Definition at line 387 of file swanser.f90.

!
!****************************************************************
!
   USE ocpcomm4
!
   IMPLICIT NONE
!
!
!   --|-----------------------------------------------------------|--
!     | Delft University of Technology                            |
!     | Faculty of Civil Engineering and Geosciences              |
!     | Environmental Fluid Mechanics Section                     |
!     | P.O. Box 5048, 2600 GA  Delft, The Netherlands            |
!     |                                                           |
!     | Programmer: M. Zijlema                                    |
!   --|-----------------------------------------------------------|--
!
!
!     SWAN (Simulating WAves Nearshore); a third generation wave model
!     Copyright (C) 2004-2005  Delft University of Technology
!
!     This program is free software; you can redistribute it and/or
!     modify it under the terms of the GNU General Public License as
!     published by the Free Software Foundation; either version 2 of
!     the License, or (at your option) any later version.
!
!     This program is distributed in the hope that it will be useful,
!     but WITHOUT ANY WARRANTY; without even the implied warranty of
!     MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the
!     GNU General Public License for more details.
!
!     A copy of the GNU General Public License is available at
!     http://www.gnu.org/copyleft/gpl.html#SEC3
!     or by writing to the Free Software Foundation, Inc.,
!     59 Temple Place, Suite 330, Boston, MA  02111-1307  USA
!
!
!  0. Authors
!
!     40.23: Marcel Zijlema
!     40.41: Marcel Zijlema
!
!  1. Updates
!
!     40.23, Feb. 03: New subroutine
!     40.41, Oct. 04: common blocks replaced by modules, include files removed
!
!  2. Purpose
!
!     Copies integer array IARR1 to IARR2
!
!  3. Method
!
!     ---
!
!  4. Argument variables
!
!     IARR1       source array
!     IARR2       target array
!     LENGTH      array length
!
   INTEGER LENGTH
   INTEGER IARR1(LENGTH), IARR2(LENGTH)
!
!  6. Local variables
!
!     I     :     loop counter
!     IENT  :     number of entries
!
   INTEGER I, IENT
!
!  8. Subroutines used
!
!     MSGERR           Writes error message
!     STRACE           Tracing routine for debugging
!
!  9. Subroutines calling
!
!     ---
!
! 10. Error messages
!
!     ---
!
! 11. Remarks
!
!     ---
!
! 12. Structure
!
!     Trivial.
!
! 13. Source text
!
   SAVE ient
   DATA ient/0/
   IF(ltrace) CALL strace (ient,'SWCOPI')

!  --- check array length

   IF(length <= 0)THEN
     CALL msgerr( 3, 'Array length should be positive' )
   END IF

!  --- copy elements of array IARR1 to IARR2

   DO i = 1, length
     iarr2(i) = iarr1(i)
   END DO

   RETURN

Here is the call graph for this function:

txpbla()

subroutine txpbla	(	character*(*)	TEXT,
		integer	IF,
		integer	IL
	)

Definition at line 202 of file swanser.f90.

!
!****************************************************************
!
   IMPLICIT NONE
!
!
!   --|-----------------------------------------------------------|--
!     | Delft University of Technology                            |
!     | Faculty of Civil Engineering and Geosciences              |
!     | Environmental Fluid Mechanics Section                     |
!     | P.O. Box 5048, 2600 GA  Delft, The Netherlands            |
!     |                                                           |
!     | Programmer: M. Zijlema                                    |
!   --|-----------------------------------------------------------|--
!
!
!     SWAN (Simulating WAves Nearshore); a third generation wave model
!     Copyright (C) 2004-2005  Delft University of Technology
!
!     This program is free software; you can redistribute it and/or
!     modify it under the terms of the GNU General Public License as
!     published by the Free Software Foundation; either version 2 of
!     the License, or (at your option) any later version.
!
!     This program is distributed in the hope that it will be useful,
!     but WITHOUT ANY WARRANTY; without even the implied warranty of
!     MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the
!     GNU General Public License for more details.
!
!     A copy of the GNU General Public License is available at
!     http://www.gnu.org/copyleft/gpl.html#SEC3
!     or by writing to the Free Software Foundation, Inc.,
!     59 Temple Place, Suite 330, Boston, MA  02111-1307  USA
!
!
!  0. Authors
!
!     40.23: Marcel Zijlema
!
!  1. Updates
!
!     40.23, Feb. 03: New subroutine
!
!  2. Purpose
!
!     determines the position of the first and the last non-blank
!     (or non-tabulator) character in the text-string
!
!  4. Argument variables
!
!     IF          position of the first non-blank character in TEXT
!     IL          position of the last non-blank character in TEXT
!     TEXT        text string
!
   INTEGER IF, IL
   CHARACTER*(*) TEXT
!
!  6. Local variables
!
!     FOUND :     TEXT is found or not
!     ITABVL:     integer value of tabulator character
!     LENTXT:     length of TEXT
!
   INTEGER LENTXT, ITABVL
   LOGICAL FOUND
!
! 12. Structure
!
!     Trivial.
!
! 13. Source text
!
!DOS      ITABVL = ICHAR('  ')
!UNIX      ITABVL = ICHAR(' ')
   lentxt = len(text)
   IF = 1
   found = .false.
100 IF(IF <= lentxt .AND. .NOT. found)THEN
     IF(.NOT. (text(if:if) ==  ' ' .OR.                   &
       ichar(text(if:if)) == itabvl))THEN
       found = .true.
     ELSE
       IF = IF + 1
     ENDIF
     GOTO 100
   ENDIF
   il = lentxt + 1
   found = .false.
200 IF(il > 1 .AND. .NOT. found)THEN
    il = il - 1
     IF(.NOT. (text(il:il) ==  ' ' .OR.                   &
       ichar(text(il:il)) == itabvl))THEN
       found = .true.
     ENDIF
     GOTO 200
   ENDIF

   RETURN

Here is the caller graph for this function:
